2.2 SCSI Function Specification
Table 2.4 shows the SCSI functions of the optical disk drive. Refer to “SCSI Logical Interface
Specifications” for details on each functions.
Table 2.4 SCSI function specifications (1 of 7)
×: Supported
–: Not supported
Item Specification
Single-ended
×
TERMPWR signal supply/demand function
×Jumper selectable
Terminating resistor On/Off function
×Jumper selectable
Connector Nonshielded
×(Protect key provided)
Data bus parity
×Switch selectable
Bus arbitration function
×
Disconnection/Reconnection function
×
Addressing SCSI ID #0 to #7 Switch selectable
LUN (Logical unit number) #0 is Fixed
Data transfer Asynchronous mode
×5 MB/s Max.
Synchronous mode
×20 MB/s Max.
Data buffer 2,016 KB
Data block length 512 bytes, 2,048 bytes
SCSI-1
×
SCSI-2
×
Electrical
requirement
