C156-E097-01EN 4 - 11
Table 4.7 SCSI terminating resistor mode (CNH1)
SCSI terminating resistor mode CNH 1 05-06
SCSI terminating resistor module on the PCA is enabled. Short (*1)
SCSI terminating resistor module on the PCA is disabled. Open
*1 Setting when delivered
Open CNH1 5-6 pins when the SCSI terminating resistor set by CHN 2-15 pin.
