Fujitsu MCE3064SS - Surface Temperature Measurement Points

3 - 2 C156-E097-01EN
(a) Inside optical disk cartridge
(b) IC (controller, read map)
Figure 3.1 Surface temperature measurement points
Hole for incerting thermo couple
IC (controller)
IC (read amp)
Tip of thermo couple
Operating of inner
partition wall
