(1) SCSI ID
Table 4.1 shows the SCSI ID settings of the drive.
Table 4.1 SCSI ID setting (SW1)
SCSI ID SW1-01 SW1-02 SW1-03
0 (*1) OFF OFF OFF
1 OFF OFF ON
2 OFF ON OFF
3 OFF ON ON
4 ON OFF OFF
5 ON OFF ON
6 ON ON OFF
7 ON ON ON
*1 Setting when delivered
1) Each SCSI device connected to the same SCSI bus must have a
unique SCSI ID.
2) If contention occurs in the ARBITRATION phase, the priority of
the SCSI use authority depends on SCSI IDs as follows:
7 >> 6 >> 5 >> 4 >> 3 >> 2 >> 1 >> 0
(2) SCSI data bus parity checking
Table 4.2 shows the settings which determine whether to check the SCSI bus parity bit.
Regardless of the settings, the parity bit is ensured for data transmitted by the drive.
Table 4.2 SCSI data bus parity checking (SW1)
SCSI data bus parity checking by drive SW1-04
Checked ON (*1)
Not checked OFF
*1 Setting when delivered
