3.4 Connection Requirement
3.4.1 Connectors and terminals
This drive is equipped with the connectors and terminals shown below for external connection.
Figure 3.13 shows their locations.
• Power supply connector
• SCSI connector
• External operator panel terminal (CNH2)
Figure 3.13 Connector and terminal locations
External operator
panel terminal
(CNH2)
