C156-E097-01EN 3 - 27
(5) Logical specification type 0
The command specification and message specification are specified. The SCSI-1 specification is
compatible with that of the old unit (M2511A). Table 3.11 shows the command and message
specification settings.
Table 3.11 Logical specification type setting
Command specification and message
specification
CNH 2/Pin 14 - GND
SCSI-2 specification Open*
SCSI-1 specification Shorted
* Setting when delivered
