C156-E097-01EN 4 - 3
Figure 4.1 Packaging style
(5) Transportation
a) Transport the package with the UP sign upward.
b) After unpacking, minimize the transportation distance and use cushions to avoid shock and
vibration. Transport the drive in one of the orientations described in Subsection 3.2.2 after
unpacking. (The horizontal direction is recommended.)
(6) Storage
a) Use moistureproof packaging when storing the drive.
b) The storage environment must satisfy the requirements specified i n Subsection 2.1.3 when
the drive is not operating.
c) To prevent condensation, avoid sharp changes in temperature.
Packaging box
Cushion (2 pcs)
MCE3064SS
MCF3064SS
Ejecting jig
