28 Service Supplement RX200 S3
Replacing the system board Replacing components
Installing the system board
Ê Insert the system board at a slight angle and push the connectors into the
external connection panel. You will have to overcome a slight spring
resistance.
Ê Carefully lower the system board into the housing.
If necessary, adjust the position of the system board by turning it slightly.
Ê Fasten the system board with the nine screws (see figure on page 27).
Ê Reconnect all cables.
I For cabling information see page 36.
Ê Reinstall the riser card holder.
1
Ê Reinstall the processor(s).
1
Ê Reinstall the memory modules in their slots.
1
I To ensure correct operation, make sure you do the following after
installing the new system board:
– Update the BMC firmware and the BIOS
– Set the BIOS default values
– Set the customer-specific settings
This completes the replacement of the system board.
1
The relevant procedure is described in the Options Guide.
