20 Operating manual RX200 S4
Technical data Preface
Mechanical values
Mechanical values
Weight
Approx. 18 kg (depending on configuration).
Ventilation clearance
At least 200 mm on the front and rear.
Ambient conditions
Condensation during operation must be avoided!
Width 430 mm
Depth 770 mm
Height 44 mm or 1 HU
Installation depth in rack 745 mm
Cable depth in rack 100.0 mm (1000 mm rack recommended)
Width (without front panel) 430 mm
Installation depth 745 mm
Total depth (with front panel) 770 mm
Height 44 mm or 1 HU
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 10 °C ... 35 °C
Transport (2K2) - 25 °C ... 60 °C
Humidity 10% ... 85%
