62 Operating manual RX200 S4
Controls and indicators Startup and operation
5.1.2 Rear of server
CSS/global error indicator and ID indicator
Figure 15: CSS/global error indicator and ID indicator
1 CSS/Global Error/ID indicator 2 ID indicator
1 CSS/global error/ID indicator (yellow/orange/blue)
CSS
Does not light up when the system is OK. No service incident or critical
event has occurred.
Flashes yellow if an error occurred that you can fix yourself with the CSS
concept (see “Customer Self Service (CSS)” on page 10). For more details
on the error, you can consult the ServerView Local Service Panel or
ServerView S2.
Lights up yellow if a prefailure event was detected for a CSS component.
Details of the event can be found in the System Event Log or using
ServerView S2. The indicator also lights up in standby mode.
If the event is still acute after a power failure, the indicator is activated after
the restart.
