Fujitsu PRIMERGY RX200 S5 User Manual

Operating Manual RX200 S5
Contents
5 Starting up and operation . . . . . . . . . . . . . . . . . . . . 55
5.1 Controls and indicators . . . . . . . . . . . . . . . . . . . . . 55
5.1.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.1.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5.1.3 Indicators of the hot-plug system fans . . . . . . . . . . . . . . 64
5.2 Switching the server on and off . . . . . . . . . . . . . . . . 65
5.3 Configuring the server . . . . . . . . . . . . . . . . . . . . . 67
5.3.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 67
5.3.2 Configuring the SAS/SATA RAID controller . . . . . . . . . . . . 67
5.3.3 Configuring the server and installing the operating system with the
ServerView Installation Manager . . . . . . . . . . . . . . . . . 68
5.3.4 Configuring the server and installing the operating system without
ServerView Installation Manager . . . . . . . . . . . . . . . . . 69
5.4 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 70
6 Property and data protection . . . . . . . . . . . . . . . . . . 71
6.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 71
7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 73
7.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 73
7.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 74
7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 74
7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 75
7.5 No screen display or display drifts . . . . . . . . . . . . . . . 75
7.6 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 76
7.7 System will not boot . . . . . . . . . . . . . . . . . . . . . . . 76
7.8 Hard disk drive error messages at system boot . . . . . . . . 76
7.9 Added drive reported as defective . . . . . . . . . . . . . . . 77
7.10 Error message on screen . . . . . . . . . . . . . . . . . . . . 77

Fujitsu PRIMERGY RX200 S5 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF9
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	2.5 \
Total storage capacity	0 GB
Internal memory	4 GB
Memory clock speed	1066 MHz
Maximum internal memory	96 GB
Memory layout (slots x size)	2 x 2 GB
Networking features	Gigabit Ethernet
Expansion slots	1x PCI-Express 2 x4 2x PCI-Express 2 x8
PS/2 ports quantity	0
USB 2.0 ports quantity	7
Ethernet LAN (RJ-45) ports	3
Power supply	459 W
Power requirements	100 - 127 V / 200 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 Microsoft Windows Server 2003 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux Citrix XenServer VMware Infrastructure VMware vSphere 4.0
Chassis type	Rack (1U)
Operating temperature (T-T)	15 - 35 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CE, CB, RoHS, WEEE
Processor ARK ID	40711

Weight and Dimensions

Depth	765 mm
Width	431 mm
Height	43 mm
