Fujitsu PRIMERGY RX200 S5 - 5 Starting up and operation; 5.1 Controls and indicators

RX200 S5 Operating Manual 55
5 Starting up and operation
V CAUTION!
Please note the safety instructions in chapter "Important information" on
page 25.
5.1 Controls and indicators
5.1.1 Front of server
Figure 12: Controls and indicators on the front
1 CPU error indicator 9 ID indicator
2 Memory error indicator 10 power-on indicator
3 PCI error indicator 11 On/Off button
4 Fan error indicator 12 ID button
5 CSS indicator 13 NMI button
6 Global Error indicator 14 Open/close DVD drive
7 hard disk activity indicator 15 CD/DVD drive activity indicator
8 reset button
햲
햽
햳 햴 햵 햶 햷 햸 햹 햺 햻
햾햿헁 헀
