TX200 S5 Options Guide 39
Processors Installing a second processor
Ê Place the processor in the socket with great care.
V CAUTION!
Do not bend the spring contacts of the processor socket. Never touch
the underside of the processor. Even light contaminants, such as oil
from human skin, can destroy the processor or impair its functionality.
Figure 20: Locking the processor
Ê Close the processor holder (1).
Ê Lock the processor in place in the socket by returning the spring clip to its
original position (2).
Ԙ
ԙ
