Fujitsu PRIMERGY TX200 S5

48 Options Guide TX200 S5
Installing an accessible 5.25-inch drive Accessible drives
V CAUTION!
If screws are too long, they may damage the drive.
Figure 28: Inserting the accessible drive - DVD example
Ê Push the drive fully into the bay until the EasyClick rails lock in place.
Accessible drive Required screws
LTO2 HH Ultrium M3 x 3.5 mm *
LTO3 HH Ultrium M3 x 3.5 mm *
LTO4 HH Ultrium M3 x 4.5 mm
DDS Gen 5 M3 x 4.5 mm
DDS Gen 6 (USB / SCSI) M3 x 4.5 mm
RDX drive M3 x 4.5 mm
* These screws are supplied with the drive.
