3.3 Loading Documents
ScanSnap S500 Operator's Guide 47
Basic Scanner Operations
3
Operation
6. Spread the page to be scanned facing outwards and fold it in half from the center.
Fold it neatly so that the folded portion does not appear puffed. If the folded portion is not
folded neatly, it may cause skewing.
7. Open the Carrier Sheet and place the document inside.
8. Load the Carrier Sheet onto the scanner.
Align the top of the document to the top of
the Carrier Sheet, and the folded
portion to the top-right corner closely.
• Place the top of the sheet with the black
& white printed pattern downwards and
load it in the direction of the arrow.
• When you load the Carrier Sheet, adjust
the side guides so that it will not skew.
• If you are using the Carrier Sheet for
scanning, it is not possible to scan
multiple sheets continuously. Load the
sheets one by one and scan.
SCAN
POWER

Fujitsu ScanSnap S500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum system requirements	Windows 2000/ XP/ Vista
Scan media weight	52 - 127 g/m²
Power requirements	AC 100V - 240V, 50 / 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
