Fujitsu ScanSnap S500 User Manual

48
9. Press the [SCAN] button.
⇒ The front and back image data are set in a facing-page state and generated side by side.
ATTENTION
• There may be a gap in the joined portion, or a line may appear in the output
image.
If you are scanning a thick document, the image has a tendency to skew in
such a way that the upper portions tilt towards each other at the joined area.
In these situations, the skew is caused by the way in which the document is
folded, or the loading method.
Do the following. The situation may be improved.
- Is the document neatly folded? If not, fold it neatly.
- Is the edge of the document aligned closely to the edge of the Carrier
Sheet? If not, align them.
- Load the Carrier Sheet by turning the front side back.
• In the "Carrier Sheet Settings" window, when "Automatic Detection" in "Output
image size" is selected, the generated image size may be smaller than the
document.
(The smallest size to include all the data on the document is selected from
among A3, B4 and 11" x 17")
Example: If the document printed as A4 size in the center of an A3 document
is scanned,
=> it is generated in B4 size.
To output an image that is the same size as the document size, set the docu-
ment size in [Output image size].

Fujitsu ScanSnap S500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum system requirements	Windows 2000/ XP/ Vista
Scan media weight	52 - 127 g/m²
Power requirements	AC 100V - 240V, 50 / 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
