Fujitsu ScanSnap S510 User Manual

5.3 Sending Files by E-Mail
ScanSnap S510 Operator's Guide 133
About Actions
5
Attached file size
When attached file size exceeds a set parameter, a Warning message appears.
You can specify a parameter between 1MB and 10MB.
* Even if you see a Warning message, you can send attached files by e-mail.
However, it is recommended that the attached file size be 2MB at the maximum
(it depends on your system environment).
5. Click the [OK] button to close the "Scan2E-mail -Options" dialog box.
HINT
When the [Settings] button of a selected action is clicked, the selected action
background color changes to yellow, and other actions become unselectable.
To select another action, first close the "Scan2E-mail - Options" dialog box, and
then click on any point in areas other than actions, or place the mouse cursor on
the selected action.
⇒ The selected action background color is changed to the original color (blue)
and other actions become selectable.
CLICK!

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
