3.3 Loading Documents
ScanSnap S510 Operator's Guide 61
Using the ScanSnap
3
7. Press the [SCAN] button .
⇒ Scanning is started and the image data is generated in the specified size.
ATTENTION
• The image is centered and output in the specified size.
When "Automatic Detection" is selected in the "Output image size" drop-
down list of the "Carrier Sheet Settings" window, an optimal size is selected
automatically from the available standard sizes (refer to page 108) and the
image is output.
• In the "Carrier Sheet Settings" window, when "Automatic Detection" is
selected in the "Output image size" drop-down list, the size of the produced
image may be smaller than the original.
Example: When you scan the A5 size image printed at the center of an A4
size paper
 A5 size image is output.
To output an image in the original size, specify the document size in the
[Output image size] drop-down list
HINT
If the following symptoms are observed, lay the material over a piece of white
paper to scan.
• The output image is not in a suitable size (when [Automatic Detection] is
selected).
• The outline of the material is shaded.
• Black lines appear around the material cut out in an indefinite shape.
white paper

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
