Fujitsu ScanSnap S510 User Manual

76
Upon clicking the [OK] button, specified settings take effect.
(An example file name in the format you select is displayed under the [Filename
format] button.)
■ Rename file after scanning
If this checkbox is marked, the "Save scanned image as" dialog box appears after
scanning.
HINT
About "Counter"
• When no file with a name specified in the "File Name" field exists in the save
folder (specified on the [Save] tab), a suffix number combined will be "1" ("001"
if 3 is selected in the "Counter" drop-down list). The number increases in
increments of 1 every time a new file is saved.
• When other files with a name specified in the "File Name" field exist in the
save folder, a number combined will be the smallest available number.
Example: When files, Scan01.pdf, Scan03.pdf, and Scan04.pdf, exist in the
same folder, the file you save next will be Scan02.pdf, and then Scan05.pdf,
Scan06.pdf, Scan07.pdf...as long as you use the same "File Name."
• When the specified number of digits is exceeded (for example, when saving
the 100th file with two digits specified), the number of digits increases by one.

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
