FULTON VSRT-60 - Control Panel Components

COMMISSIONING - 4
Fulton Ltd
Table 7 - Steam Program for Siemens LMV3*
Par.No.
Parameter
Min Value
Max Value
Fulton Setting
Customer
163
Operating hours when unit is live
0h
99999999h
164
Number of start-ups resettable
0
99999999
166
Total number of start-ups
0
9999999
167
Fuel volume resettable
0
99999999
200
Burner Control
201
Burner operating mode (fuel train,
modulating/ multistage, actuators, etc.)
--=undefined (delete curves)
1=G mod
2=Gp1 mod
3=Gp2 mod
4=Lo mod
5=Lo2-stage
6=Lo3-stage
7=G modpneu
8=Gp1modpneu
9=Gp2modpneu
10=LoGp mod
11=LoGp 2-stage
12=Lomod2fuelvalves
13=LoGpmod2fuelvalves 14=Gmod
pneu without actuator
15=Gp1modpneuwithoutactuator
16=Gp2modpneuwithoutactuator
17=Lo2-stufigwithoutactuator
18=Lo3-stufigwithoutactuator
19=G mod only gas actuator
20=Gp1mod only gas actuator
21=Gp2modonlygasactuator 22=Lo
mod only oil actuator
1
22
3
208
Program stop
0=deactivated
1=PrePurgP (Ph24)
2=IgnitPos (Ph36)
3=interval1 (Ph44)
4=interval2 (ph52)
0
4
0
210
Alarm in the event of start
prevention 0=deactivated
1=activated
0
1
0
211
Fan ramp up time
2s
60s
5s
212
Max time down to low fire
0.2s
10min
30s
10s
213
Min time homerun
2s
60s
2s
214
Max time start release
0.2s
10min
20s
215
Repetition limit safety loop
1
16
1
217
Max time to detector signal
5s
10min
30s
221
Gas: Active detector flame
evaluation 0=QRB/QRC
1=ION/QRA
0
1
1
222
Gas: Pre-purging
0=deactivated
1=activated
0
1
1
*Data is for reference purposes only. Fulton Companies is not responsible for this product, including (but not limited to) its accuracy, reliability, and safety.
No Fulton document should substitute for full review of documentation available from the product manufacturer.
VSRT-IOMM-2019-1
Page 39
