Page #116 background imageLoading...
Page #116 background image
1. RADAR OPERATION
1-90
1.49 Color and Brilliance Sets
This radar provides four sets of color and brilliance sets to match any ambient
lighting condition. The default colors are as shown in the table below. The default
brilliance setting for any item is “50%”.
BRILL1 BRILL2 BRILL3 BRILL4
Echo Yellow Yellow Yellow Yellow
Inside Display,
Outside Display
Black, Black Black, Black Blue, Black Blue, Blue
Menu Yellow Yellow Yellow Yellow
Characters Green Red Green White
Bearing Scale Blue Red White Green
1.49.1 Choosing color and brilliance set
1. Roll the trackball to choose the BRILL box at the left side of the screen.
2. Roll the wheel to choose color and brilliance set from among BRILL1 –
BRILL4.
3. Push the wheel to finish.
1.49.2 Presetting color and brilliance set
1. Roll the trackball to choose the BRILL box at the left side of the screen.
2. Push the right button to open the BRILL menu.
[BRILL1 MENU (1/2)]
1 ECHO COLOR
YEL/GRN/
WHT/COLOR*
2 BKGD COLOR
BLK-GRN/
BLK-RED/
BLU-CIR/
BLU/BRT-BLU
3 PANEL DIMMER
4 CHARACTER
5 CURSOR
6 ECHO
7 TRAIL
8 HL
9 RING
0 NEXT
* Not available on IMO or A type
BRILL menu
3. Roll the wheel to choose 1 ECHO COLOR and then push the wheel or the
left button.
4. Roll the wheel to choose echo color desired and then push the wheel or the
left button. “COLOR,” available on the A, B, C and W types, displays echoes
in colors of red, yellow and green, corresponding to signal levels of strong,
medium and weak.
