4. AIS OPERATION
4-2
[ARP•AIS]
1 BACK
2 GUARD ZONE STAB
STAB HDG/STAB NORTH
3 GUARD POLYGON
OFF/STAB GND/
STAB HDG/STAB NORTH
4 [TRIAL MANEUVER]
5 [ARP SYMBOL]
6 [AIS SYMBOL]
7 [FUSION]
8 AIS FUNCTION
OFF/ON
9 AIS LOST ALARM
ACTIVATED TARGET/
ALL TARGET/
RANGE
0nm
4.2 Enabling/Disabling the AIS
1. Roll the trackball to choose the MENU box at the right side of the screen and
then push the left button.
2. Roll the wheel to choose 4 ARP•AIS and then push the wheel or the left
button.
ARP•AIS menu
3. Roll the wheel to choose 8 AIS FUNCTION and then push the wheel or the
left button.
4. Roll the wheel to choose OFF or ON as appropriate and then push the wheel
or the left button.
5. Push the right button twice to close the menu.
“AIS” appears at the lower right hand corner of the screen when the AIS function
is active.
