3. ARP OPERATION
3-20
[ARP•AIS]
1 BACK
2 GUARD ZONE STAB
STAB HDG/STAB NORTH
5 GUARD POLYGON
OFF/STAB GND/
STAB HDG/STAB NORTH
4 [TRIAL MANEUVER]
5 [ARP SYMBOL]
6 [AIS SYMBOL]
7 [FUSION]
8 AIS FUNCTION
OFF/ON
9 AIS LOST ALARM
ACTIVATED TARGET/
ALLTARGET/
RANGE
0nm
[ARP SYMBOL]
1 BACK
2 ARP SYMBOL COLOR
RED/GRN/BLU/YEL/
CYA/MAG/WHT
3 ARP SYMBOL SIZE
SMALL/STD/LARGE
4 PAST POSN COLOR
RED/GRN/BLU/YEL/
CYA/MAG/WHT
5 PAST POSN POINTS
5/10
3.10.2 Past position display attributes
You may choose the number of past point points to display per plotting interval
and the color of past position points.
1. Roll the trackball to choose the MENU box at the right side of the screen and
then push the left button.
2. Roll the wheel to choose 4 ARP•AIS and then push the wheel or the left
button.
ARP•AIS menu
3. Roll the wheel to choose 5 [ARP SYMBOL] and then push the wheel or the
left button.
ARP SYMBOL menu
4. Roll the wheel to choose 4 PAST POSN COLOR and then push the wheel.
5. Roll the wheel to choose color desired and then push the wheel.
6. Roll the wheel to choose 5 PAST POSN POINTS and then push the wheel.
7. Roll the wheel to choose 5 or 10 as appropriate and then push the wheel.
8. Push the right button three times to close the menu.
