5. VIDEO PLOTTER OPERATION
5-33
5.13.6 Displaying nav line, waypoint mark
Displaying internal nav lines
1. Roll the trackball to choose the MENU box and then push the left button.
2. Roll the wheel to choose 8 [NAV LINE•WPT] and then push the wheel or the
left button.
3. Roll the wheel to choose 2 NAV LINE DATA and then push the wheel or the
left button.
4. Roll the wheel to choose INTERNAL DATA and then push the wheel or the
left button.
5. Roll the wheel to choose 3 NAV LINE SELECT and then push the wheel or
the left button.
6. Use the wheel to enter the nav line number you want to display. Roll the
wheel to choose numeral and push it to set. Note that the same nav line no.
cannot be entered more than once.
7. Use FORWARD or REVERSE to choose the order to display waypoints on
the nav line. FORWARD to display them in original order or REVERSE to
display them in reverse order. Choose appropriate option and then push the
wheel.
8. To skip the next waypoint, roll the wheel to choose 2 SKIP NEXT WPT and
then push the wheel or the left button.
9. Push the right button twice to close the menu.
Displaying external nav lines
Nav lines from an external navigator can be displayed as below. RTE and WPL
sentences are necessary to display a nav line from a navigator.
1. Roll the trackball to choose the MENU box and then push the left button.
2. Roll the wheel to choose 8 [NAV LINE•WPT] and then push the wheel or the
left button.
3. Roll the wheel to choose 2 NAV LINE DATA and then push the wheel or the
left button.
4. Roll the wheel to choose EXT DATA and then push the wheel or the left
button.
5. Do the following as appropriate:
1)
Set width (0.0-9.9 nm) of the nav line with 5 NAV LINE WIDTH.
2)
Turn waypoint number display on or off with 4 DSP WPT NO (page 2 of NAV
LINE•WPT menu).
3) Set turning line with 3 TURNING LINE (page 2 of NAV LINE•WPT menu).
6. Push the right button two or three times depending on which page of the NAV
LINE•WPT menu you are using.
To Next Page
