SYSTEM CONFIGURATION
xvii
Blackbox type
ANTENNA UNIT
(Performance Monitor PM-51 built in
FAR-2137S-BB)
FAR-2137S-BB/FR-2167DS-BB
PROCESSOR UNIT
RPU-013
Sub Display
VGA
MONITOR
CONTROL UNIT
RCU-014
(Keyboard)
or
RCU-015
(Trackball)
Control Unit
RCU-016
(Remote)
AIS
: Option
: Dockyard supply
: Standard
Category of Units
Antenna unit: Exposed to weather
All other units: Protected from weather
FAR-2117-BB/2127-BB/FAR-2157-BB
ANTENNA UNIT
(Performance Monitor PM-31 built in
FAR-2117-BB, FAR-2127-BB)
24 VDC
or
100-115 VAC/
220-230 VAC
1φ, 50/60 Hz
Rectifier
RU-3424
RU-1746B-2
Transformer Unit
RU-1803
440 VAC
1φ, 50/60 Hz
DC spec
AC spec
100/110/115/
220/230 VAC
1φ, 50/60 Hz
VDR
External Monitor
Alarm
Navigator (INS, GPS, etc.)
IEC-61162-1 Serial Data
(Input/Output)
IEC-61162-1 Serial Data
(Input)
Speed Log
Gyrocompass
AD-100
Track Control Unit
Memory Card
Interface Unit
CU-200
OR
Memory Card
Interface Unit
CU-200 x 2
Switching Hub
HUB-100
HUB has ports for connection of up to 7 processor units
100-230 VAC
* Neither FAR-2157-BB nor
FAR-2167DS-BB carry a
performance monitor.
POWER SUPPLY UNIT
PSU-006
(For FAR-2157-BB/2167DS-BB)
OR
POWER SUPPLY UNIT
PSU-007
(For FAR-2137S-BB/2837S-BB)
