5. VIDEO PLOTTER OPERATION
5-5
• To continue entering the same mark or line (with the guidance box showing
“MARK / EXIT”), roll the trackball to choose location and then push the left
button.
• To quit entering marks or lines, push the right button when the guidance box
reads “MARK / EXIT.”
B, C and W types
(symbols available in 7 colors)
IMO and A types
Orange MARK Orange MARK
Orange MARK Orange MARK
Orange MARK Orange MARK
Orange MARK Orange MARK
Orange MARK Orange MARK
Orange MARK Orange MARK
Orange MARK Green BUOY
Orange MARK Red BUOY
Orange MARK Green BUOY
Orange MARK Red BUOY
<>
Orange MARK Green BUOY
Orange MARK Red BUOY
Red BUOY Green BUOY
Red BUOY Red BUOY
Red BUOY Purple DANGER
Red BUOY Purple DANGER
Red BUOY Purple DANGER (cable)
Purple DANGER White COAST LINE
Purple DANGER (cable) Gray CONTOUR LINE
Purple DANGER Purple NAV LINE
White COAST LINE Purple PROHIBITED AREAS
Gray CONTOUR LINE
Purple NAV LINE
Purple PROHIBITED AREAS
