1. RADAR OPERATION
1-65
[ECHO]
1 BACK
2
PICTURE/
IR
ES/
EAV/
NOISE REJ/
ANT SELECT/
PULSE LENGTH/
A/C SEA SELECT/
AUTO RAIN SELECT/
TUNE SELECT/
ANT HEIGHT/
SEA CONDITION/
2ND ECHO REJ/
PM*
1
/
SART
[ARP•
IS]
1 BACK
2
DISP ARP/
DISP AIS/
TARGET DATA & ACQ/
PAST POSN INTERVAL/
REF MARK/
CPA LIMIT/
CPA/
TCPA/
GZ1/
GZ2/
TARGET LIST SORT/
TRIAL MANEUVER/
ARP•AIS FUSION/
AIS MESSAGE
TRIAL MODE CHANGE
[STD KEY]
1 BACK
2
ALARM ACK/
STBY TX/
HL OFF/
EBL OFFSET/
MODE/
OFF CENTER/
CU TM RESET/
INDEX LINE/
VECTOR TIME/
VECTOR MODE/
TARGET LIST/
TRAIL/
BRILL/
MARK/
MENU/
RANGE UP/
RANGE DOWN/
ACQ/
TARGET DATA/
TARGET CANCEL
[OPERATION]
1 BACK
2
ECHO COLOR/
BACK COLOR/
RING/
ALARM1/
ALARM2/
WATCH ALARM RESET/
ZOOM/
MARK DELETE/
OWN TRACK DELETE/
TGT TRACK DELETE/
CHART ALIGN/
DISPLAY SELECT/
MOB/
USER DEFAULT
OWN TRK ALL ERASE
TGT TRK ALL ERASE
MARK ALL ERASE
4. Roll the wheel to choose appropriate category, ECHO, STD KEY, ARP•AIS,
OPERATION or PICTURE and then push the wheel or the left button. Refer
to the menus below to choose appropriate category.
[PICTURE]
1 BACK
2
PICTURE1/
PICTURE2/
PICTURE3/
PICTURE4/
NEAR/
FAR/
NEAR BUOY/
FAR BUOY/
ROUGH SEA/
SHIP/
HARBOR*
1
/
COAST*
1
/
NEAR BIRD*
2
/
FAR BIRD*
2
*
1
Models other than
FAR-2157, FAR-2167DS
*
2
FAR-2157, FAR-2167DS only
To Next Page
