1. OPERATION
1-42
Items displayable in (4) - (9)
Depth, position (lat/lon), speed (SOG), speed (STW), COG, water temperature,
heading
4. Press the KNOB.
Note 1: If necessary data is not input below items cannot be selected.
Note 2: If data from the connected device is interrupted for 30 seconds, "- - - -"
will be displayed.
Necessary data Item
Longitude/latitude position Lat/Lon, course over ground (COG), XTE
Heading Heading
Ship speed Speed over the ground (SOG), speed through the water (STW)
Wind speed, wind angle Wind speed, wind direction
Atmospheric pressure Atmospheric pressure
Water temp. Water temperature
Depth Position (Lat/Lon) Speed (SOG) Speed (STW)
Water temperature Heading
COG
True (or Mag) True (or Mag)
DEPTH POSITION SPEED (SOG) SPEED (STW)
COURSE
TEMP HEADING
