APPX. 2 TRANSDUCER LIST

AP-6

Other compatible transducers

Single Frequency CHIRP Transducers

Dual Frequency CHIRP Transducers

Transducer

ACCU-

FISH

™

Bottom

Discrimination

RezBoost

™

Hardness Remarks

B150M  300W

SS75L  

B75M  600W

SS75M  

B785M  

SS75H  

TM165HW  

B175M  1kW (FCV-800 only)

TM185M  

B285M  

B175HW  

TM185HW  

B285HW  

Transducer

ACCU-

FISH

™

Bottom

Discrimination

RezBoost

™

Hardness Remarks

B265LM  1kW (FCV-800 only)

TM265LM  

CM265LM  

B275LHW  

TM275LHW  

CM275LHW  
