Sensor
Description
Component
RAID Presence
RAID controller card
presence
RAID controller card
LCD Status
LCD health status
LCD
LCD Presence
LCD presence
LCD
PS Redundancy
Redundancy failure due
to PSU removal
PSU
NIC# Status
NIC fault diagnosis health
status
LOM port
Port# Link Down
Network port link status
LOM port
PSN Status
PSU status
PSUN
N indicates the PSU
number. The value is 1 or
2.
PSN Fan Status
PSU fan status
PSU N
N indicates the PSU
number. The value is 1 or
2.
PSN Temp Status
PSU presence
PSU
N indicates the PSU
number. The value is 1 or
2.
DISKN
Drive status
Drive N
N indicates the drive slot
number. The value
ranges from 0 to 47.
LOM P1 Link Down
LOM
LOM
LOM P2 Link Down
LOM
LOM
LOM P3 Link Down
LOM
LOM
LOM P4 Link Down
LOM
LOM
PCIe RAID$ Temp
PCIe RAID controller card
temperature
PCIe RAID controller card
M2 Temp(PCIe$)
Maximum temperature of
all M.2 drives of the RAID
controller card
PCIe RAID controller card
RAID Temp
RAID controller card
temperature
RAID controller card
RAID Status
RAID controller card
health status
RAID controller card
