FusionServer 5288 V5 Server
Technical White Paper
A Appendix
Issue 07 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
93
Sensor
Description
Component
number. The value is 1 or
2.
CPUN Memory
CPU memory status
DIMMs of CPU N
N indicates the CPU
number. The value is 1 or
2.
FANN Status
Fan status
Fan module N
N indicates the fan
module number. The
value ranges from 1 to 4.
DIMMN
DIMM status
DIMMN
N indicates the DIMM slot
number.
RTC Battery
RTC battery status. An
alarm is generated when
the voltage is lower than 1
V.
RTC battery
PCIE Status
PCIe status
PCIe card
Power Button
Power button pressed
state
Mainboard and power
button
Watchdog2
Watchdog timer
Mainboard
Mngmnt Health
Management subsystem
health status
Management module
UID Button
UID button status
Mainboard
PwrOk Sig. Drop
Voltage dip status
Mainboard
PwrOn TimeOut
Power-on timeout
Mainboard
PwrCap Status
Power capping status
Mainboard
HDD Backplane
Entity presence
Drive backplane
HDD BP Status
Drive backplane health
status
Drive backplane
RiserN Card
Entity presence
Riser card N
N indicates the riser card
number. The value
ranges from 1 to 3.
SAS Cable
Entity presence
SAS high-speed cable
FANN Presence
Fan presence
Fan module N
N indicates the fan
module number. The
value ranges from 1 to 4.
