FusionServer 5288 V5 Server
Technical White Paper
A Appendix
Issue 07 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
92
Sensor
Description
Component
PCH VPVNN
PCH VPVNN voltage
Mainboard
PCH PRIM 1V05
PCH PRIM voltage
Mainboard
CPUN VCCP
CPU VCCP voltage
Mainboard
N indicates the CPU
number. The value is 1 or
2.
CPUN DDR VPP1
VPP_ABC voltage
Mainboard
N indicates the CPU
number. The value is 1 or
2.
CPUN DDR VPP2
VPP_DEF voltage
Mainboard
N indicates the CPU
number. The value is 1 or
2.
FANN Speed
Fan speed sensor
Fan module N
N indicates the fan
module number. The
value ranges from 1 to 4.
Power
Server input power
PSU
PSN VIN
PSUN input voltage
PSUN
N indicates the PSU
number. The value is 1 or
2.
Disks Temp
Drive maximum
temperature
Drive
Powern
PSU input power
PSUN
N indicates the PSU
number. The value is 1 or
2.
PCH Status
PCH chip fault diagnosis
health status
Mainboard
CPUN QPI Link
CPU QPI link fault
diagnosis health status
Mainboard or CPUN
N indicates the CPU
number. The value is 1 or
2.
CPUN Prochot
CPU Prochot
CPUN
N indicates the CPU
number. The value is 1 or
2.
CPUN Status
CPU status
CPUN
N indicates the CPU
