GAGGIA ANIMA 03 USER INSTRUCTIONS
Pag. 3/3
The machine is out of service
If the machine error alarm signal is triggered, the error code is
displayed in the bottom right corner of the display.
(Following table)
XX
Red Display
Error
code
Behaviour Cause Action
1
Coffee grinder
blocked
Coffee outlet duct
clogged
Clean the coffee outlet duct thoroughly.
3 - 4
Brew group locked,
cannot be taken out
The brew group is
incorrectly positio-
ned.
Close the service door. Turn the machine off
and back on again. Wait for the ‘Ready for
brewing’ signal and then remove the brew
group.
5 Water circuit error
Air in the water
circuit
Remove and restore the water tank a couple
of times, making sure to position it correctly.
Check that the water tank seat is clean.
3.2. Operation, cleaning and maintenance
Operating the machine
1 Fill water tank
2
Fill the coffee bean hop-
per
3 Switch on the appliance
4
Press the button to start
the appliance
5 Heating When the heating phase begins, wait for it to fi nish
6 Rinse Carry out a rinse cycle for the internal circuits
7 Machine ready The machine is ready to dispense beverages
CLEANING AND TECHNICAL SERVICING
A Empty the dregs drawer When indicated
B Empty the drip tray As necessary
C Clean the water tank Weekly
D Clean the coffee bean hopper As necessary
E Clean the casing As necessary
F
Clean the brewing unit Every time the coffee bean hopper is fi lled or weekly
Lubricate the brewing unit
After 500 dispensing cycles or when the grease is
no longer present on the brewing unit
Clean the unit housing Weekly
H Descaling When indicated
