1.6.1. External machine parts Anima XL
1 ESPRESSO button
ESC button
2 ESPRESSO LUNGO button
3 AROMA STRENGTH button
OK button
4 CAPPUCCINO button
UP button
5 LATTE MACCHIATO button
6 MENU button
DOWN button
7 STAND-BY button
8 Display
In the example:
Main menu; ready for brewing
M
A
X
M
I
N
7
8
11
10
3
1
4
5
6
2
9
12
14
13
P
U
S
H
N
M
A
X
M
I
N
M
A
X
2
10
9
8
1
11
3
12
4
7
5
6
1 STAND-BY button
2 Water tank seat
3 Coffee bean hopper
4 Removable water tank
5 Main switch
I. ON
0. OFF
6 Power cord socket
7 Coffee grounds drawer
8 Drip tray
9 Drip tray grill
10 Coffee dispensing spout
11 Hot water dispensing spout
12 Milk carafe
1 Water tank lid
2 Coffee bean hopper lid
3 Service door
4 Coffee residues drawer
5 Brew group
6 Coffee dispensing spout
7 Drip tray
8 Coffee grounds drawer
9 ‘Drip tray full’ indicator
10 Hot water dispensing spout
11 Milk carafe lid
12 Milk carafe top
13 Milk frother dispensing spout
14 Milk container
1
8
2
3
4
5
6
7
ESPRESSO
ESPRESSO LUNGO
AROMA STRENGTH
CAPPUCCINO
LATTE MACCHIATO
MENU
