GAGGIA ANIMA 04 OPERATING LOGIC
Pag. 7/10
The machine uses an ALGORITHM that considers the current absorbed by the coffee grinder,
beside it considers if the grinder is old or new and if it is warm or cold.
1) When the system get the stability (i.e. the system got the current target) the coffee doses
should be:
A1 A2/3 A4/5
7,5 9,0 10 ±1,5 grams
with medium grinding (500±60μm) and using coffee of test.
2) the 3 grinding times are always:
T
1<T2<T3
beside, every grinding time is, respectively:
4,0s ≤T3 ≤10s (10000ms)
3,5s ≤T2 ≤9s (9000ms)
3,0s ≤T1 ≤8,1s (8100ms)
4.10. Coffee lack detection and coffee grinder blocked
DOSE ADJUSTMENT
5 levels
Grinder
Time
Min
Grinder
Time
Max
Grinder
Time
Curret target
Aroma
of the
grinded
product
Aroma1
Very Light
T1 3s 8,1s I0 + 55mA
Aroma2
Light
T2 3,5s 9s I0 + 100mA
Aroma3
Med
Aroma4
Strong
T3 4s 10s I0 + 200mA
Aroma5
Very Strong

Gaggia Anima Specifications

General

Product type	Espresso machine
Capacity in cups	- cups
Coffee input type	Coffee beans, Ground coffee
Coffee maker type	Fully-auto
Country of origin	Italy
Appliance placement	Countertop
Water tank capacity	1.8 L
Coffee beans capacity	250 g
Maximum operating pressure	15 bar
Number of grinder settings	5
Reservoir for brewed coffee	Cup
Number of temperature settings	3
Adjustable coffee spout height range	110 - 150 mm
Control type	Buttons
Display type	LCD
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS), Stainless steel
Multi beverage	-
Quantity per pack	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	1 W

Weight and Dimensions

Depth	430 mm
Width	221 mm
Height	340 mm
Weight	7900 g
