Gaggia Anima - Milk Carafe Mechanism

GAGGIA ANIMA 04 OPERATING LOGIC
Pag. 2/10
4.2. Milk Carafe
1) Steam input
2)Bring the cappuccino maker into dispensing
position
3) Milk tank
1
2
3
The steam passes
through the pipe creating
a sucking effect that pulls
the milk upwards
Steam
The milk is heated by the
steam and taken towards
the emulsion chamber
where it is mixed with
air and transformed into
foam
