164 • Appendices DMC-1500
57 57 XAB+ X Auxiliary encoder B+
Rev A + B
Terminal #
Rev C
Terminal #
Label Description
58 60 XAA- X Auxiliary encoder A-
59 59 XAA+ X Auxiliary encoder A+
60 62 GND Ground
61 61 5V 5 Volts
62 64 LSCOM Limit common
63 63 FLSX X Forward limit
64 66 RLSX X Reverse limit
65 65 HOMEX X Home Input
66 68 FLSY Y Forward limit
67 67 RLSY Y Reverse limit
68 70 HOMEY Y Home
69 69 FLSZ Z Forward limit
70 72 RLSZ Z Reverse limit
71 71 HOMEZ Z Home
72 74 FLSW W Forward limit
73 73 RLSW W Reverse limit
74 76 HOMEW W Home
75 75 GND Ground
76 78 ABORT Abort input
77 77 XA+ X Main encoder A+
78 80 XA- X Main encoder A-
79 79 XB+ X Main encoder B+
80 82 XB- X Main encoder B-
81 81 XI+ X Main encoder I+
82 84 XI- X Main encoder I-
83 83 YA+ Y Main encoder A+
84 86 YA- Y Main encoder A-
85 85 YB+ Y Main encoder B+
86 88 YB- Y Main encoder B-
87 87 YI+ Y Main encoder I+
88 90 YI- Y Main encoder I-
89 89 ZA+ Z Main encoder A+
90 92 ZA- Z Main encoder A-
91 91 ZB+ Z Main encoder B+
92 94 ZB- Z Main encoder B-
93 93 ZI+ Z Main encoder I+
94 96 ZI- Z Main encoder I-
95 95 WA+ W Main encoder A+
96 98 WA- W Main encoder A-
To Next Page
