178 • Appendices DMC-1500
Pin Block Bit No. SBn,@IN[n] Pin
27 7 2 59 28 Ground
29 7 1 58 30 Ground
31 7 0 57 32 Ground
33 6 7 56 34 Ground
35 6 6 55 36 Ground
37 6 5 54 38 Ground
39 6 4 53 40 Ground
41 6 3 52 42 Ground
43 6 2 51 44 Ground
45 6 1 50 46 Ground
47 6 0 49 48 Ground
49 5 volts 50 Ground
JD3 Pinout (Note: All points are inputs on this cable):
Pin Block Bit No. @IN[n] Pin
1 11 7 96 2 Ground
3 11 6 95 4 Ground
5 11 5 94 6 Ground
7 11 4 93 8 Ground
9 11 3 92 10 Ground
11 11 2 91 12 Ground
13 11 1 90 14 Ground
15 11 0 89 16 Ground
17 10 7 88 18 Ground
19 10 6 87 20 Ground
21 10 5 86 22 Ground
23 10 4 85 24 Ground
25 10 3 84 26 Ground
27 10 2 83 28 Ground
29 10 1 82 30 Ground
31 10 0 81 32 Ground
33 9 7 80 34 Ground
35 9 6 79 36 Ground
37 9 5 78 38 Ground
39 9 4 77 40 Ground
41 9 3 76 42 Ground
43 9 2 75 44 Ground
45 9 1 74 46 Ground
47 9 0 73 48 Ground
49 5 volts 50 Ground
