6

Usinganexternal12voltbattery
TochargetheScale'sinternalbatteryusinganexternal12voltbattery,follow
thesesteps:
1. ConnectthesuppliedblackandredbatteryleadstotheScale.
2. Connecttheotherendofthebatteryleadstothe12voltbattery.

ConnecttheRedcliptothePositiveterminal.
ConnecttheBlackcliptotheNegativeterminal.
3. OpentheScalecaseandmakesurethebatterychargeicon on
themainscreenisflashing.Thisindicatesthatthebatteryischargingand
willbedisplayedwhethertheScaleisturnedonoroff.
Batterychargestatus
ThebatteryicondisplaysinthebottomleftcorneroftheScale'supperscreen.
Itisimportanttonotethatthebatteryiconwillonlyevershowtheactual
amountofchargeleftinthebatterywhentheScaleisturnedonand
disconnectedfromexternalpower.
FullyCharged BatteryIconbarsarealldisplayedconstantly.
Partially
Charged
BatteryIconshowsfirstfourbarsconstantly.
BatteryFlat NoBatteryIconbarsaredisplayed.
WhentheScaleisconnectedtotheexternalpowersupplythebatteryiconwill
displaythechargingstatus.
Charging BatteryIconshowsallthebarsconstantlyfilling
andthendisappearing.
ToppingUp BatteryIconshowsthefirstfourbarsconstantly
fullandtheremainderfillingandthen
disappearing.
TrickleCharge BatteryIconshowsonlyoneemptybarthatis
constantlytravellingthelengthofthefullIcon.

