Garmin ECHOMAP PLUS User Manual

Specifications
All Models
Specification Measurement
Material Polycarbonate plastic
Water rating IEC 60529 IPX7
6
Temperature range From -15° to 55°C (from 5° to 131°F)
Input voltage From 9 to 18Vdc
Fuse 3A, 125V fast-acting
Compass-safe distance 65cm (25.6in.)
NMEA 2000 LEN @ 9Vdc
7
1
NMEA 2000 draw
7
75mA max.
Memory card 1 microSD card slot; 32 GB max. card size
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
4-Inch Models
Specification Measurement
Dimensions on mount (W x H x D) 10.2 x 16.5 x 0.4cm (4.0 x 6.5 x 3.1in.)
Display size (W x H) 5.4 x 9.5cm (2.1 x 3.7in.), 10.5cm (4.3in.) diagonal
Display resolution WQVGA, 480 x 272 pixels
Weight 0.7kg (1.6lbs.)
Compass-safe distance 25cm (9.8in.)
Input voltage From 9 to 18Vdc
Max. power draw 5W
Typical current draw (RMS) 0.5A
Max. current draw 2A
6
The device withstands incidental exposure to water of up to 1m for up to 30min. For more information, go to www.garmin.com/waterrating.
7
NMEA 2000 is not available in the ECHOMAP Plus 40 models.
Appendix 113

Garmin ECHOMAP PLUS Specifications

General

Water Rating	IPX7
Display Resolution	800 x 480 pixels
Mounting Options	Flush mount
Transmitter Power	500W (RMS)
Sonar	CHIRP traditional, CHIRP ClearVü, CHIRP SideVü
GPS	Built-in high-sensitivity GPS and GLONASS receiver
Mapping	Preloaded BlueChart g2 coastal charts or LakeVü g3 inland maps
Connectivity	NMEA 0183
Storage	MicroSD card slot
Display Size	7 inches
