Introduction
WARNING
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
ECHOMAP Plus 40 Device View
Device keys
microSD
®
memory card slot
Power and transducer connectors
Beeper
NOTICE
Each time you place the device in the bracket, you should make sure the device is firmly secured in the cradle,
the cables are fully pushed into the device and cradle, and the locking bracket is snapped firmly closed. There
is an audible click when the device or locking bracket is installed correctly. If the cables are not fully seated and
the device is not firmly secured, it can lose power or stop working. The device can also fall out of the cradle and
become damaged if it is not firmly secured.
Introduction 1
