Garmin ECHOMAP PLUS - 6-Inch Models

6-Inch Models
Specification Measurement
Dimensions on cradle and bail mount with swivel base (W x H x D) 21.8 x 13.0 x 6.2cm (8.6 x 5.1 x 2.6 in.)
Display size (W x H)
13.7 x 7.7cm (5.4 x 3.1in.)
15.2cm (6.2in.) diagonal
Display resolution WVGA, 400 x 800pixels
Weight 0.75kg (1.6lb.)
Compass-safe distance 65cm (25.6in.)
Clearance to nearest obstruction 8.0cm (3.14in.)
Max. power draw 12W
Typical current draw at 12Vdc (RMS) 0.7A
Max. current draw at 12Vdc 1.25A
Wireless frequency 2.4 GHz @ 17.2 dBm maximum
7-Inch Models
Specification Measurement
Dimensions on cradle and bail mount (W x H x D) 25.9 x 15.4 x 6.3cm (10.2 x 6 x 2.5in.)
Display size (W x H)
15.5x 8.7cm (6.1 x 3.4in.)
17.8cm (7in.) diagonal
Display resolution WVGA, 400 x 800pixels
Weight 0.77kg (1.7lb.)
Clearance to nearest obstruction 11.5cm (4.5in.)
Max. power draw 15W, 9W with a GT-52 transducer
Typical current draw at 12Vdc (RMS) 0.8A
Max. current draw at 12Vdc 2.1A
Wireless frequency 2.4 GHz @ 18.5dBm maximum
114 Appendix
