Garmin G1000 NXi Service Manual

G1000 NXi System Maintenance Manual Page 207
King Air 300 Series Revision 1
190-00716-N1
NOTE
The 3
rd
item on the checklist instructs the operator to “prepare a detailed test
sequence with precise start and stop times for exercising all electronic devices”.
The list of relevant electronic devices are given in Table 5-5. Begin test with flaps
retracted, flight controls in a neutral position, all lights selected OFF.
Elapsed Time since Start of Test
(min:secs)
Action
0:00
Test begins
0:05
Tail Flood lights on
0:10
Tail Flood lights off
0:20
Navigation lights on
0:30
Navigation lights off
0:40
Landing lights on
0:50
Landing lights off
1:00
Taxi lights on
1:20
Taxi lights off
1:40
Strobes on
1:50
Strobes off
2:00
Recognition lights on
2:10
Recognition lights off
2:20
Beacon on
2:30
Beacon off
2:40
Rudder full left
2:50
Rudder full right
3:00
Rudder Trim full left
3:10
Rudder Trim full right
3:20
Elevator full nose UP
3:30
Elevator full nose DN
3:40
Elevator trim full nose UP
(manual electric)
3:50
Elevator trim full nose DN
(manual electric)
4:00
End of test
Table 5-5, Magnetometer Interference Test Sequence
6. When the CALIBRATE field is blinking, press the ENT key to begin the procedure, and
have a stopwatch ready to begin recording the elapsed time.
NOTE
It is important that the “time equals zero” moment corresponds with the
moment the PFD first displays the blinking TEST COMPLETE? Message.

Garmin G1000 NXi Specifications

General

Manufacturer	Garmin
Display Type	LCD
Resolution	1024 x 768 pixels (XGA)
Power Supply	28 VDC
Operating Temperature	−20°C to +55°C
