Garmin G1000 Cockpit Reference Guide

Garmin G1000 Cockpit Reference Guide for the Socata TBM 850
190-00708-00 Rev. A
SECTION 11 – ADDITIONAL
FEATURES
11-12
9) For event-based messages:
a) Use the FMS Knob to enter the desired date (DD-
MM-YY) and press the ENT Key.
b) Press the ENT Key again or use the large FMS Knob
to move the cursor to the next field.
c) Use the FMS Knob to enter the desired time (HH:
MM) and press the ENT Key.
10) Press the ENT Key again or use the large FMS Knob
to move the cursor to enter the next message.
Deleting a Scheduler Message
1) Select the AUX - Utility Page.
2) Press the FMS Knob momentarily to activate the
flashing cursor.
3) Turn the large FMS Knob to highlight the name
field of the scheduler message to be deleted.
4) Press the CLR Key to clear the message text. If
the CLR Key is pressed again, the message is
restored.
5) Press the ENT Key to confirm message deletion.
Scheduler messages appear in the Alerts Window on
the PFD and cause the ALERTS Softkey label to change to
ADVISORY. Selecting the ADVISORY Softkey opens the
Alerts Window and acknowledges the scheduler message.
The softkey revers to the ALERTS label and when selected,
the Alerts Window is removed from the display and the
scheduler message is deleted from the message queue.
Figure 11-20 PFD Alerts Window

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
