Garmin G1000 Cockpit Reference Guide for the Socata TBM 850
190-00708-00 Rev. A
13-19
SECTION 13 – ANNUNCIATIONS
& ALERTS
GDL 69A Message Advisories
Message Comments
GDL69 CONFIG
– GDL 69 config
error. Config service req’d.
GDL 69 configuration settings do not match those of backup configuration
memory. The G1000 system should be serviced.
GDL69 FAIL
– GDL 69 has failed. A failure has been detected in the GDL 69. The receiver is unavailable. The
G1000 system should be serviced
MANIFEST
– GDL software mismatch,
communication halted.
The GDL 69 has incorrect software installed. The G1000 system should be
serviced.
GWX 68 Alert Messages
Message Comments
GWX CONFIG
– GWX config error.
Config service req’d.
GWX 68 configuration settings do not match those of the GDU configuration.
The G1000 system should be serviced.
GWX FAIL
– GWX is inoperative. The GDU is not recieving status packet from the GWX 68 or the GWX 68 is
reporting a fault. The GWX 68 radar system should be serviced.
GWX SERVICE
– GWX needs service.
Return unit for repair.
A failure has been detected in the GWX 68. The GWX 68 may still be usable.
WX ALERT
– Possible severe weather
ahead.
The GWX 68 indicates severe weather within ±10º of the aircraft heading at a
range of 80 to 320 nm.
MANIFEST
– GWX software
mismatch, communication halted.
The GWX 68 has incorrect software installed. The G1000 system should be
serviced.
GDC 74B Message Advisories
Message Comments
ADC1 ALT EC
– ADC1 altitude error
correction is unavailable.
GDC1 or GDC2 is reporting that the altitude error correction is unavailable.
ADC2 ALT EC
– ADC2 altitude error
correction is unavailable.
ADC1 AS EC
– ADC1 airspeed error
correction is unavailable.
GDC1 or GDC2 is reporting that the airspeed error correction is unavailable.
ADC2 AS EC
– ADC2 airspeed error
correction is unavailable.
