GNS 430 Pilot’s Guide and Reference
10-12
SECTION 10
AUX PAGES
10.3 UTILITY PAGE
The Utility Page (Figure 10-29) provides access (via
‘menu options’) to checklists, a count down/up timer,
trip timers, trip statistics, RAIM (Receiver Autonomous
Integrity Monitoring) prediction, sunrise/sunset time
calculations, software versions, database versions, and
terrain database version information. When a menu
option is selected, the corresponding page appears
providing additional information and features.
NOTE: Scroll down to view the last 3 items
(Software Versions, Database Versions, and
Terrain Database Versions) listed on the Utility
Page.
Figure 10-29 Utility Page
Current Page Group
Menu Options (to Select,
Highlight with Cursor and
Press the ENT Key)
Position of
Current Page
within Current
Page Group
Number of Pages in
Curr
ent Page Group
To select a menu option from the Utility
Page:
1) Press the small right knob momentarily,
to activate the flashing cursor (Figure
10-29).
2) T
urn the large right knob to select the desired
me
nu option (Figure 10-30), and press the ENT
Key (Figure 10-31).
Figure 10-30 Sunrise/Sunset Highlighted
Figure 10-31 Waypoint Field Highlighted
The following menu options are available:
• Checklists - Provides up to nine different user-
defined checklists containing up to 30 items each.
• Flight T
imers - Provides count up/down timers,
plus automatic recor
ding of departure time and
total trip time. Departure and total trip time
recording can be configured to run either any time
GNS 430 power is on, or only when the ground
speed exceeds 30 knots.
• Trip Statistics - Provides readouts for trip
odometers, average speed, and maximum speed.
These readouts ar
e resettable (individually or all
at once) by pressing the MENU Key to display the
Trip Statistics Page Menu.
