Introduction
MX20 Installation Manual 560-1025-09 Rev E 5
Table 1-1. Installation Package Contents
Part # Description
Quantity
w/o GPS
424-0751
Quantity
w/ GPS
Quantity
w/ I/O
424-0753
Unit
430-0270-0( ) MX20 Multifunction Display with GPS 1
430-0270-5( ) MX20 Multifunction Display without GPS 1
430-0270-6( ) MX20 I/O Traffic Multifunction Display 1
430-0270-7( ) MX20 I/O Traffic/Radar Multifunction Display 1
MX20 Installation Kit
115-0007-00 GPS 1575 MHz 2:1 Splitter 1
162-1008 Right Angle Coax Plug 1
162-1060 TNC Connector 3
162-1577** 37-Pin D-Sub 1 1 1
202-0001 Cable Tie 4 4 4
204-0037 Edge Grommet 6" 6" 6"
204-2100 Shoulder Bushing 2
220-0637 6-32 Wing Nut 1 1 1
240-0615 #6 Washer 2 2 2
224-0404 4-40 X 1/4 SS Flat Head Phillips Machine Screw 2 2 2
245-0027** Crimp Contact For D-Sub, 20 To 24 AWG Wire 30 30 40
310-0429-( ) MFD Mounting Tube 1 1 1
998-0048 3/32" Hex Driver 1 1 1
MX20 I/O Installation Kit
160-0138 62-Pin D-Sub, High Density 1
245-0059 Crimp Contact For High Density D-Sub, 22 To 30 AWG Wire 20
564-0076-0( )
Manual Kit
1 1 1
140-0059-0( ) MX20 & i-linc MFDs Product CD 1 1 1
560-1025-( ) MX20 Installation Manual 0* 0* 0*
560-1026-( ) MX20 Pilot’s Guide 1* 1* 1*
561-0263 MX20 Quick Reference Guide 1* 1* 1*
564-0078-0( )
Or
560-1055-0( )
STC Kit (AFMS & MDL)
Or
STC Index (AFMS, RFMS, MDL, STC, AML, etc.)
0* 0* 0*
Notes:
* These documents are currently included in the product CD.
** Pin has a barrel over the contact. Use ITT Cannon tools.
Other Required Materials
The MX20 equipment is intended for use with standard aviation accessories. See Section 2.3.1 for a list
of compatible equipment. The following items are required for the installation:
 Compatible position locating source, such as: GX50/55/60/65 GPS receiver, or CNX-series (or
GNS 480) receiver
 Compatible Serial Altitude Encoder

 Sixteen AN507 or MS24693 6-32 cadmium-plated carbon steel screws with 100º countersink flat
heads to secure the mounting tube to the aircraft structure.

