Specifications
MX20 Installation Manual 560-1025-09 Rev E 51
Velocity...........................................................1000 knots maximum
Acceleration ....................................................4G maximum
TTFF (time to first fix) ...................................25 seconds typical with current almanac, position, time, and
ephemeris
55 seconds typical with current almanac, position, and time
Reacquisition ..................................................2.5 seconds typical
Position update interval ..................................1 second typical
Datum..............................................................WGS-84
3.1.15 Weather Radar and Functions
Table 3-4 shows which radar sensors and radar functions are supported by the MX20.
Table 3-4. Radar Sensors and Supported Radar Functions
GWX 68
(Garmin PN 011-00883-20)
RS-181A
(
King PN 071-1315-00)
(Bendix/King PN 3614077-
8101)
ART 2000 (
Bendix/King PN 071-01519-
0101)
ART 2100 (Bendix/King PN 071-01550-
0101)
OFF OFF OFF
STANDBY STANDBY STANDBY
ON ON ON
TEST TEST TEST
HORIZONTAL SCAN HORIZONTAL SCAN HORIZONTAL SCAN
VERTICAL SCAN VERTICAL SCAN
GAIN ADJUSTMENT GAIN ADJUSTMENT GAIN ADJUSTMENT
TILT ADJUSTMENT TILT ADJUSTMENT TILT ADJUSTMENT
BEARING ADJUSTMENT BEARING ADJUSTMENT
RANGE SETTINGS RANGE SETTINGS RANGE SETTINGS
MAP SCAN MAP SCAN MAP SCAN
WX SCAN WX SCAN WX SCAN
ROLL TRIM ROLL TRIM ROLL TRIM
HOLD HOLD HOLD
SECTOR SCAN
STABILIZATION STABILIZATION STABILIZATION
CALIBRATION CALIBRATION CALIBRATION
NOTE: The ART 2100 is supported when configured to emulate an ART 2000. Only ART 2000 functions
are available.
