I/O Specifications
A-4 560-1025-09 Rev E MX20 Installation Manual
A.3 Flight Plan Waypoint Types (when Extended Data is Enabled
Only)
The following data is only transmitted when preceded by flight plan data. There is one character per
flight plan waypoint transmitted.
Table A-4. Flight Plan Waypoint Type
Id Item
Format
Len Description
t nnn… 1-21 n = { a (airport) ||
v (VOR) ||
n (NDB) ||
i (intersection) ||
u (user) ||
p (parallel track) ||
d (direct to) ||
F (FAF) ||
I (IAF) ||
H (MAHP) ||
A (IFAF) ||
P (undefined approach waypoint type) }
Example Moving Map Data Output (Extended Data Disabled)
  3415.70’ latitude
   11843.90’ longitude
     306 track angle
     210 knots
    268.2nm to waypoint
    0.6nm right of course
 305.9 desired track
     SFO waypoint ident
 305.8 bearing to waypoint
 14.0 east magnetic variation
  No alarms, data not flagged
  !"#$%"&"'  From Table 3-6
Figure A-1. Moving Map Data Output (Extended Data Disabled)
