I/O Specifications
MX20 Installation Manual 560-1025-09 Rev E A-5
Example Moving Map Data Output (Extended Data Enabled)
  3415.70’ latitude
   11843.90’ longitude
     306 track angle
     210 knots
    268.2nm to waypoint
    0.6nm right of course
 305.9 desired track
     SFO waypoint ident
 305.8 bearing to waypoint
 14.0 east magnetic variation
  No alarms, data not flagged
  !"#$%"&"'  From Table 3-2
"(   Approach Enabled Off, Active Off, Message On, Parallel Track
Off, Hold Off, and From/To is FROM
 )*  CDI Valid, Needle Right, Deflection 001
 * VDI Valid, Needle Centered, Deflection is 000
  !"#$%"&"' From Table A-3
&%"  Flight Plan Waypoint Type data, direct-to, airport type
Figure A-2. Moving Map Data Output (Extended Data Enabled)
